Xsens Humanoid — Pro — Dongle — Lifetime
By xsens
Robotics-oriented motion capture with processing and export capabilities. Supported formats and integrations differ between Windows and Linux.
Compatible with Windows · Linux
Request a quote. Public pricing is not displayed.
License: Dongle — Lifetime
Your Configuration
- Quote required. Knoxlabs confirms availability, lead time and the selected configuration before ordering.
- A perpetual license is not a promise of lifetime software updates. Maintenance and support depend on the applicable agreement.
🛠
Deployment Expertise
XR specialists on staff
⚙
Device Configuration
Provisioned & ready to use
🎧
Enterprise Support
Hardware, software & deployment help
🌐
Global Fulfillment
Shipped worldwide
Features
- Core purpose—Up to two actors; HD reprocessing, export and extended kinematics for robotics workflows.
- Windows exports—MP4, extended-kinematics MVNX, XLSX, BVH and NVIDIA Isaac MCAP.
- Linux exports—MVNX, BVH and NVIDIA Isaac MCAP are listed for Pro.
- License scope—Software entitlement in the selected deployment and term; no capture hardware implied.
Technical Specifications
Everything you need to know about tracking, performance, connectivity, and deployment hardware.
Selected configuration
- Product
- Xsens Humanoid — Pro — Dongle — Lifetime
- Configuration
- Dongle — Lifetime
Technical details
- Core purpose
- Up to two actors; HD reprocessing, export and extended kinematics for robotics workflows.
- Windows exports
- MP4, extended-kinematics MVNX, XLSX, BVH and NVIDIA Isaac MCAP.
- Linux exports
- MVNX, BVH and NVIDIA Isaac MCAP are listed for Pro.
Edition capabilities
- Connect Xsens hardware — Windows
- Supported
- Record MVN files — Windows
- Supported
- Upload files to Xsens MotionCloud — Windows
- Supported
- Xsens Suit configurations — Windows
- Full bodyLower bodyUpper bodyFull body no handsUpper body no handsLower body with sternum
- Subjects/Actors — Windows
- Up to 2
- Xsens Prop tracking — Windows
- MVN Link and Awinda: Up to 4 Xsens Link: 1
- Reprocess (HD) — Windows
- Supported
- Exporting — Windows
- Supported
- Export formats — Windows
- Mp4 (movie)MVNX (with extended kinematics)XLSX (Excel)BVH NVIDIA Isaac (.mcap)
- Scenarios — Windows
- Single LevelMulti LevelNo LevelSoft Floor
- Finger tracking:Xsens Metagloves / Metagloves ProXsens Prime 3 by ManusStretchSense — Windows
- Supported
- UDP Remote Control — Windows
- Supported
- Reference Camera — Windows
- Supported
- Soft access point — Windows
- Supported
- Network Streaming Position Orientation — Windows
- Supported — compatible with:ROS
- Network Streaming - extended dataJoint anglesAccelerationCoM — Windows
- Supported — compatible with:ROS
- 3D Position Aiding — Windows
- Supported — Compatible with: HTC Vive / Vive MarsGNSS (GPS)
- Object Tracking — Windows
- Supported — Compatible with: HTC Vive / Vive Mars
- Network Sync — Windows
- Supported
- Hardware Sync (TTL) — Windows
- Supported
- Timecode (LTC) — Windows
- Supported
- On Body Recording (OBR)*On Body Recording (OBR) in the Xsens Link*Link hardware only — Windows
- Supported
- Remote On Body Recording (rOBR)*Link hardware only — Windows
- Supported
- Biomechanical ModelLegacyMaleFemale — Windows
- Supported
- Live graphs — Windows
- Supported
- External Data — Windows
- Supported — Compatible with: EMG
- Connect Xsens hardware — Linux
- Supported
- Record MVN files — Linux
- Supported
- Upload files to Xsens MotionCloud — Linux
- Not supported
- Xsens Suit configurations — Linux
- Full bodyLower bodyUpper bodyFull body no handsUpper body no handsLower body with sternum
- Subjects/Actors — Linux
- Up to 2
- Xsens Prop tracking — Linux
- MVN Link and Awinda: Up to 4 Xsens Link: 1
- Reprocess (HD) — Linux
- Supported
- Exporting — Linux
- Supported
- Export formats — Linux
- MVNX BVH NVIDIA Isaac (.mcap)
- Scenarios — Linux
- Single LevelMulti LevelNo LevelSoft Floor
- Finger tracking:Xsens Metagloves / Metagloves ProXsens Prime 3 by ManusStretchSense — Linux
- Not supported
- UDP Remote Control — Linux
- Not supported
- Reference Camera — Linux
- Not supported
- Soft access point — Linux
- Not supported
- Network Streaming Position Orientation — Linux
- Supported — compatible with:ROS
- Network Streaming - extended dataJoint anglesAccelerationCoM — Linux
- Supported — compatible with:ROS
- 3D Position Aiding — Linux
- Not supported
- Object Tracking — Linux
- Not supported
- Network Sync — Linux
- Supported
- Hardware Sync (TTL) — Linux
- Not supported
- Timecode (LTC) — Linux
- Not supported
- On Body Recording (OBR)*On Body Recording (OBR) in the Xsens Link*Link hardware only — Linux
- Supported
- Remote On Body Recording (rOBR)*Link hardware only — Linux
- Not supported
- Biomechanical ModelLegacyMaleFemale — Linux
- Supported
- Live graphs — Linux
- Supported
- External Data — Linux
- Not supported
- Operating-system support in release 2026.8 — Windows
- Supported
- Operating-system support in release 2026.8 — Linux
- Supported
Compatibility and deployment
- Compatibility
- Compatible capture hardware, software version and edition-dependent integrations must be confirmed.
- Scope / supplied item
- Software entitlement in the selected deployment and term; no capture hardware implied.
- Licensing / requirements
- Current-book configuration: Dongle — Lifetime. Dongle-based activation; verify whether a physical key is included. Perpetual entitlement does not include updates forever. Release 2026.8: Windows 11 or Ubuntu 24.04.4 LTS, with edition/platform-specific features.
Product details
Overview
Selected configuration
License: Dongle — Lifetime
Software for bringing human motion into robot teleoperation, simulation, and motion-data workflows.
The Pro edition supports advanced motion-data processing and export workflows. Exact integrations and supported hardware depend on the software release.
A lifetime base-license entitlement does not imply unlimited software maintenance or support. Coverage beyond the included support period must be quoted separately.
The June 2026 supplier price list includes one year of support with Humanoid licenses. Software maintenance is separate unless expressly included in the confirmed Academic offer.
License configuration
- Edition: Xsens Humanoid Pro
- Deployment: Dongle
- Term: Lifetime
- Order type: New license
Compatible motion-capture hardware and any separately required license dongle are not included unless stated in your quote. Knoxlabs will confirm activation, operating-system compatibility, seats, and delivery before order placement.
Request a quote: Availability, lead time, licensing eligibility, and the final configuration are confirmed before ordering. Public pricing is not displayed.
Need More Than Hardware?
Knoxlabs also handles the deployment.
Device setup
MDM enrollment
Asset tagging
Shipping coordination
User onboarding
XR deployment consulting
FAQ
Which configuration is this listing for?
Xsens Humanoid — Pro — Dongle — Lifetime. Selected option: Dongle — Lifetime.
What should be confirmed before ordering?
Compatible capture hardware, software version and edition-dependent integrations must be confirmed. Current-book configuration: Dongle — Lifetime. Dongle-based activation; verify whether a physical key is included. Perpetual entitlement does not include updates forever. Release 2026.8: Windows 11 or Ubuntu 24.04.4 LTS, with edition/platform-specific features. Quote required. Knoxlabs confirms availability, lead time and the selected configuration before ordering. A perpetual license is not a promise of lifetime software updates. Maintenance and support depend on the applicable agreement.
What is included?
Software entitlement in the selected deployment and term; no capture hardware implied.
