Xsens Humanoid — Live — Network — 1 Year Extension
By xsens
Live motion-data streaming for robotics/teleoperation workflows; Windows and Linux capabilities must be described separately.
Compatible with Windows · Linux
Request a quote. Public pricing is not displayed.
Your Configuration
- Quote required. Knoxlabs confirms availability, lead time and the selected configuration before ordering.
- This is an extension for a qualifying existing entitlement, not a new base license.
🛠
Deployment Expertise
XR specialists on staff
⚙
Device Configuration
Provisioned & ready to use
🎧
Enterprise Support
Hardware, software & deployment help
🌐
Global Fulfillment
Shipped worldwide
Features
- Core purpose—One actor; body configurations including no-hands options; ROS position/orientation and extended-data streaming.
- License scope—Software entitlement in the selected deployment and term; no capture hardware implied.
Technical Specifications
Everything you need to know about tracking, performance, connectivity, and deployment hardware.
Selected configuration
- Product
- Xsens Humanoid — Live — Network — 1 Year Extension
- Configuration
- Network — 1 Year Extension
Technical details
- Core purpose
- One actor; body configurations including no-hands options; ROS position/orientation and extended-data streaming.
Edition capabilities
- Connect Xsens hardware — Windows
- Supported
- Record MVN files — Windows
- Supported
- Upload files to Xsens MotionCloud — Windows
- Supported
- Xsens Suit configurations — Windows
- Full bodyLower bodyUpper bodyFull body no handsUpper body no handsLower body with sternum
- Subjects/Actors — Windows
- 1
- Xsens Prop tracking — Windows
- MVN Link and Awinda: Up to 4 Xsens Link: 1
- Reprocess (HD) — Windows
- Not supported
- Exporting — Windows
- Not supported
- Export formats — Windows
- Not supported
- Scenarios — Windows
- Single LevelMulti LevelNo LevelSoft Floor
- Finger tracking:Xsens Metagloves / Metagloves ProXsens Prime 3 by ManusStretchSense — Windows
- Supported
- UDP Remote Control — Windows
- Supported
- Reference Camera — Windows
- Supported
- Soft access point — Windows
- Supported
- Network Streaming Position Orientation — Windows
- Supported — compatible with:ROS
- Network Streaming - extended dataJoint anglesAccelerationCoM — Windows
- Supported — compatible with:ROS
- 3D Position Aiding — Windows
- Not supported
- Object Tracking — Windows
- Not supported
- Network Sync — Windows
- Supported
- Hardware Sync (TTL) — Windows
- Supported
- Timecode (LTC) — Windows
- Supported
- On Body Recording (OBR)*On Body Recording (OBR) in the Xsens Link*Link hardware only — Windows
- Not supported
- Remote On Body Recording (rOBR)*Link hardware only — Windows
- Not supported
- Biomechanical ModelLegacyMaleFemale — Windows
- Supported
- Live graphs — Windows
- Not supported
- External Data — Windows
- Supported — Compatible with: EMG
- Connect Xsens hardware — Linux
- Supported
- Record MVN files — Linux
- Supported
- Upload files to Xsens MotionCloud — Linux
- Not supported
- Xsens Suit configurations — Linux
- Full bodyLower bodyUpper bodyFull body no handsUpper body no handsLower body with sternum
- Subjects/Actors — Linux
- 1
- Xsens Prop tracking — Linux
- MVN Link and Awinda: Up to 4 Xsens Link: 1
- Reprocess (HD) — Linux
- Not supported
- Exporting — Linux
- Not supported
- Export formats — Linux
- Not supported
- Scenarios — Linux
- Single LevelMulti LevelNo LevelSoft Floor
- Finger tracking:Xsens Metagloves / Metagloves ProXsens Prime 3 by ManusStretchSense — Linux
- Not supported
- UDP Remote Control — Linux
- Not supported
- Reference Camera — Linux
- Not supported
- Soft access point — Linux
- Not supported
- Network Streaming Position Orientation — Linux
- Supported — compatible with:ROS
- Network Streaming - extended dataJoint anglesAccelerationCoM — Linux
- Supported — compatible with:ROS
- 3D Position Aiding — Linux
- Not supported
- Object Tracking — Linux
- Not supported
- Network Sync — Linux
- Supported
- Hardware Sync (TTL) — Linux
- Not supported
- Timecode (LTC) — Linux
- Not supported
- On Body Recording (OBR)*On Body Recording (OBR) in the Xsens Link*Link hardware only — Linux
- Not supported
- Remote On Body Recording (rOBR)*Link hardware only — Linux
- Not supported
- Biomechanical ModelLegacyMaleFemale — Linux
- Supported
- Live graphs — Linux
- Not supported
- External Data — Linux
- Not supported
- Operating-system support in release 2026.8 — Windows
- Supported
- Operating-system support in release 2026.8 — Linux
- Supported
Compatibility and deployment
- Compatibility
- Compatible capture hardware, software version and edition-dependent integrations must be confirmed.
- Scope / supplied item
- Software entitlement in the selected deployment and term; no capture hardware implied.
- Licensing / requirements
- Current-book configuration: Network — 1 Year Extension. Network-seat deployment; seat count and server requirements need confirmation. Renewal/extension requires an eligible existing license. Release 2026.8: Windows 11 or Ubuntu 24.04.4 LTS, with edition/platform-specific features.
Product details
Overview
Selected configuration
License: Network — 1 Year Extension
Software for bringing human motion into robot teleoperation, simulation, and motion-data workflows.
The Live edition focuses on real-time streaming. Pro-only processing and export features are not implied by this license.
Renewal/extension: Requires an eligible existing license. Please provide its license ID and expiry date so the correct extension can be confirmed.
The June 2026 supplier price list includes one year of support with Humanoid licenses. Software maintenance is separate unless expressly included in the confirmed Academic offer.
License configuration
- Edition: Xsens Humanoid Live
- Deployment: Network
- Term: 1 Year
- Order type: Extension of an existing license
Compatible motion-capture hardware and any separately required license dongle are not included unless stated in your quote. Knoxlabs will confirm activation, operating-system compatibility, seats, and delivery before order placement.
Request a quote: Availability, lead time, licensing eligibility, and the final configuration are confirmed before ordering. Public pricing is not displayed.
Need More Than Hardware?
Knoxlabs also handles the deployment.
Device setup
MDM enrollment
Asset tagging
Shipping coordination
User onboarding
XR deployment consulting
FAQ
Which configuration is this listing for?
Xsens Humanoid — Live — Network — 1 Year Extension. Selected option: Network — 1 Year Extension.
What should be confirmed before ordering?
Compatible capture hardware, software version and edition-dependent integrations must be confirmed. Current-book configuration: Network — 1 Year Extension. Network-seat deployment; seat count and server requirements need confirmation. Renewal/extension requires an eligible existing license. Release 2026.8: Windows 11 or Ubuntu 24.04.4 LTS, with edition/platform-specific features. Quote required. Knoxlabs confirms availability, lead time and the selected configuration before ordering. This is an extension for a qualifying existing entitlement, not a new base license.
What is included?
Software entitlement in the selected deployment and term; no capture hardware implied.
