Xsens MVN Link with MVN Link Suit - Wireless fullbody mocap system

Xsens MVN Link with MVN Link Suit - Wireless fullbody mocap system

by xsens
Request a Quote
Size: MVN Link Only
Condition: New
Return Policy
Shipping and delivery
Ships within 5-10 days
Overview

This Xsens Link system is End-of-Life (EOL). For new projects, please use the Next-Generation Xsens Link .

MVN Link is a comprehensive motion capture system packed with features. Sporting 18 wired sensors, a practical Lycra full-body suit, and GNSS integration, this top-tier system is geared towards precision-seeking users. Data accuracy, a broadened range of motion, and reliable GNSS support make the MVN Link ideal for motion capture. Whether used for biomechanics, animation, sports analysis or anything else, the MVN Link is a powerful and cutting-edge system.

NOTE: MVN Link Lycra Suit for use with MVN Link systems is optional

See more below...

MVN Link Suit Sizes

Xsens MVN Link Sizes

Features
  • Superior Motion Capture: Enhance the quality and accuracy of your data with MVN Link’s 18 wired sensors.
  • Ultimate Freedom: MVN Link offers on-body recording and storage, giving you the freedom to capture motion without restrictions.
  • Enhanced Durability: Robust design capable of withstanding high-impact activities.
  • Magnetic Immunity: Capture data without interference from magnetic fields.
  • Real-time Visualization: Witness super-fast, real-time visualizations of your capture.
  • GNSS (GPS) Support: Track outdoor movements with precision.
Specifications
Feature Specification
Battery Life 10 hours
Casing Rugged pelican case
Charging Charging station for battery pack
Clothing Optional full body Lycra suits
Finger Tracking Compatibility Stretchsense, Xsens Metagloves by Manus
GNSS (GPS) Yes
Hardware Synchronization Optional, with an additional Awinda station
Latency 20 ms
On-body Buffering 10 minutes
Sensors 17 wired sensors (+1 prop sensor)
Update Rate 240 Hz
Wireless Communication Wi-Fi
Wireless Datalink Access point (supports multiple persons)
Wireless Range 150 m
In the Box

Xsens MVN Link Only

  • 4 x MVN Link MTx string (string: 3 x Orientation Trackers (2000 deg/s, 16g))
  • 6x MVN Link MTx Orientation Tracker (hands + feet + backup/prop)
  • 1 x MVN Link Sensor Body Pack Cable Upper-body
  • 1 x MVN Link Sensor Body Pack Cable Lower-body
  • 1 x MVN Link Y Split for prop Sensor
  • 1 x MVN Link Body Pack v2
  • 1 x MVN Link Body Pack Battery
  • 1 x MVN Link Battery Strap
  • 1 x MVN Link Battery Cable
  • 1 x MVN Link Battery Charger
  • 1 x MVN Link Access Point
  • 1 x MVN Segmometer
  • 1 x MVN Link Rugged pelican suitcase
  • 1 x Charging cable MTw

With MVN Link Suit

MVN Link Suit includes:

  • size S, M, L, XL, XXL, XXXL
  • a pair of gloves,
  • a pair of footpads,
  • a pair of shorts,
  • a headband
  • and a bag.

Design Highlights

Ultra-small trackers

The ultra small trackers allow for rolls and stunts. The trackers are designed to withstand high impact.

Sportive design

Sportive looking motion capture suit with accompanying shorts.

On-body zippers

The zippers give easy access to all trackers for a very fast setup.

Specifications

Specifications

Max update rate։ 240 Hz

Wireless range։ 150 m

Battery life։ 10 hours

Wireless communication: Wi-Fi

Finger tracking: Full compatibility with Xsens Gloves by Manus

Hardware: 17 wired sensors (plus 1 prop sensor)

Clothing: Full body lycra suits (one suit is included, choose your size when ordering)

Hardware synchronization: Optional, with additional Awinda station

Charging: Charging station for battery pack

Wireless datalink: Dongle antenna (1 per person)

Latency: 20 ms

On-body buffering: 10 min

Casing: Rugged pelican case

GNSS (GPS): Yes

On-Body Recording (OBR): Yes

Remote On-Body Recording (rOBR): Yes

MVN Link case with contents

MVN Link case with contents

The MVN Link System arrives in a strong, durable and watertight case. The case has wheels and an extendable handle for easy transportation. The suitcase dimensions meet the requirements for most airline hand-luggage.
The suitcase contains:
• 4 MTx String with three trackers
• 6 Motion Trackers (MTx)
• 1 Body Pack
• 1 Battery Pack
• 1 Battery charger
• 1 Access Point
• 1 Upper Body Cable
• 1 Lower Body Cable
• 1 Battery Cable
• 1 Y Cable
• 1 Segmometer
• Quick set-up sheet

You may also need

Manus Gloves for the Finger Tracking

Legacy Xsens Link vs Next-Generation Xsens Link – Full System Comparison

Feature / Capability Legacy MVN Link Xsens Link (Next Gen) Future / Planned Notes
Wi-Fi Connectivity Wi-Fi 2.4/5 GHz Wi-Fi 6E (2.4/5/6 GHz)New — Lower latency, faster throughput.
Ethernet Direct normal UTP Ethernet Rugged USB-C OTG EthernetNew — Improved stability and speed.
On-Body Recording (OBR) Supported with remote OBR Supports time-synced (local only) Remote OBR planned Adds wireless recording control.
Bluetooth / NFC Not available Hardware present, disabled Future roadmap For remote control and accessories.
Sync / Timecode Software-only Hardware port present, inactive Future roadmap Will enable LTC.
Soft Access Point Mode Yes Not in MVP Planned Hub to act as local Wi-Fi router.
Voice Prompts Beeper only Full voice alertsNew Enhanced guidance planned Adds natural feedback during setup.
LED Feedback Basic indicator Advanced multi-LED arrayNew — Expanded patterns for user clarity.
Suit Design Removable harness Integrated washable harnessNew — Faster setup, easier maintenance.
Sensor Swappability Fixed per suit Interchangeable, pre-programmed sensor locationsNew — Easier service and scalability.
System Upgradeability Limited Modular firmware + hardware-readyNew Ongoing Designed for future-proof development.
GPS Supported, when bought additionally No GPS hardware support Future roadmap Future possibility via APP or BLE/USB GPS devices.
Waterproofness Limited (not designed) Designed for IP68 docked sensors and IP44 HubNew Future roadmap – Hub waterproof housing No warranty for immersion.
Internal Battery Charging with external battery No internal battery Not supported at MVP Planned shortly after 30% charged to keep hot-swapping enabled and minimize losses.
Additional Props 1> Up to 4 Up to 4 with Additional Prop Splitters Future roadmap 1 prop sensor is included.
USB File Access Not supported Not in MVP Future roadmap Connect as storage device to PC.
Strap-Based Link Link shirt and strap set available Not at launch Shortly after launch Flexible system setup.
Sparse Sensor Setup Always full body sensors Possible to connect only upper or lower body sensor strings — No need for all sensors or cables.
USB OTG Devices No OTG support Supports Ethernet at launchNew Others on future roadmap Third-party devices through USB-C.
Wi-Fi Connectivity
Legacy: Wi-Fi 2.4/5 GHz
Next Gen: Wi-Fi 6E (2.4/5/6 GHz)
Planned: —
Notes: Lower latency and higher throughput.
Ethernet
Legacy: Direct normal UTP Ethernet
Next Gen: Rugged USB-C OTG Ethernet
Planned: —
Notes: Improved stability and field durability.
On-Body Recording (OBR)
Legacy: Supported with remote OBR
Next Gen: Time-synced local OBR only
Planned: Remote OBR
Notes: Remote control to be added via firmware.
Bluetooth / NFC
Legacy: Not available
Next Gen: Hardware present, disabled
Planned: Future roadmap
Notes: Intended for remote control and accessories.
Sync / Timecode
Legacy: Software-only
Next Gen: Hardware port present (inactive)
Planned: LTC Timecode support
Notes: For tighter multi-system sync.
Soft Access Point Mode
Legacy: Yes
Next Gen: Not in MVP
Planned: AP Mode
Notes: Hub will act as local Wi-Fi router.
Voice Prompts
Legacy: Beeper only
Next Gen: Full voice alerts
Planned: Enhanced guidance
Notes: Gives natural feedback during setup and capture.
LED Feedback
Legacy: Basic indicator
Next Gen: Advanced multi-LED array
Planned: —
Notes: Clearer power, Wi-Fi, and error states.
Suit Design
Legacy: Removable harness
Next Gen: Integrated washable harness / eSuit
Planned: —
Notes: Faster setup and easier maintenance.
Sensor Swappability
Legacy: Fixed per suit
Next Gen: Interchangeable, pre-programmed sensors
Planned: —
Notes: Easier service and scalability.
System Upgradeability
Legacy: Limited
Next Gen: Modular firmware + hardware-ready
Planned: Ongoing
Notes: Built for long-term platform evolution.
GPS
Legacy: Supported when bought additionally
Next Gen: No GPS hardware support
Planned: Possible via external devices
Notes: May be added via APP or BLE/USB GPS.
Waterproofness
Legacy: Limited (not designed)
Next Gen: IP68 docked sensors, IP44 Hub
Planned: Hub waterproof housing
Notes: Better protection but no immersion warranty.
Internal Battery Charging with external battery
Legacy: No internal battery
Next Gen: Not supported at MVP
Planned: Shortly after release
Notes: Internal battery will keep ~30% charge to support hot-swap.
Additional Props
Legacy: Up to 4
Next Gen: Up to 4 with Additional Prop Splitters
Planned: Future roadmap
Notes: One prop sensor included as standard.
USB File Access
Legacy: Not supported
Next Gen: Not in MVP
Planned: Future roadmap
Notes: Will allow direct storage access to PC.
Strap-Based Link
Legacy: Link shirt and strap set available
Next Gen: Not at launch
Planned: Shortly after launch
Notes: New T-shirt + strap configuration in progress.
Sparse Sensor Setup
Legacy: Always full-body sensors
Next Gen: Upper-body or lower-body strings only
Planned: —
Notes: No need for all sensors or cables in every setup.
USB OTG Devices
Legacy: No OTG support
Next Gen: Supports Ethernet at launch
Planned: More OTG devices
Notes: Third-party devices via USB-C are on the roadmap.

The legacy MVN Link is now End-of-Life (EOL).
For new projects, we recommend upgrading to the Next-Generation Xsens Link full system to benefit from the latest hardware, workflow improvements, and forward roadmap.
